Context Menu

The context menu is the right-click (or keyboard-invoked) menu the chart shows over its panes, objects, and scales. The model is typed and action-based: item processors and renderer hooks let hosts add, filter, or fully re-render items without losing the menu's built-in awareness of what was clicked.

State shown: the chart context menu open over the main pane of the BTCUSDT 15m chart in the dark theme.

Menu states by target

Each menu state defines its trigger, target, available actions, customization boundary, and keyboard access.

Chart pane

• Trigger: right-click or the keyboard context-menu command over empty chart space.
• Target: the invocation point — local pixel point, projected time, bar index, and price.
• Available actions: chart actions only, plus registered host actions projected to 'context-menu'.
• Customization boundary: hosts add items through registerAction and filter or reorder through itemsProcessor; built-in chart actions remain SDK-owned.
• Keyboard access: focus enters the menu on open; Escape returns focus to the trigger.

Drawing or marker

• Trigger: right-click the object.
• Target: the object plus its projected chart coordinates.
• Available actions: object actions such as inspect, settings, or remove, plus host actions the itemsProcessor allows for that object kind.
• Customization boundary: context.object identifies the target so processors can scope host items (for example, drawing-only actions).
• Keyboard access: focus a chart object and invoke its context menu; Escape returns focus to the object.

Price scale

• Trigger: right-click the price axis.
• Target: the scale and the projected price.
• Available actions: scale modes, reset, and configured price actions.
• Customization boundary: scaleContextMenuVisible: false hides the built-in scale-context section without disabling the chart pane context menu or the broader price-action menu.
• Keyboard access: same enter/Escape focus contract as the other targets.

Customize the menu

const ui = chart.customization();

const dispose = ui.registerAction({
  id: 'host.inspect-object',
  label: 'Inspect object',
  placements: ['context-menu'],
  run(context) {
    console.log(context.object, context.point, context.time, context.barIndex, context.price);
  },
});

ui.setContextMenu({
  enabled: true,
  scaleContextMenuVisible: true,
  actionIds: ['host.inspect-object'],
  itemsProcessor(items, context) {
    return context.object?.kind === 'drawing'
      ? items
      : items.filter((item) => item.id !== 'host.inspect-object');
  },
});

• Register actions with registerAction and project them through ContextMenuCustomization.
• Filter or reorder known items through itemsProcessor.
• Supply host-owned rendering through ContextMenuCustomization.renderer.

Use processor hooks to filter or render the menu items and object context supplied by TradeScript. Keep business rules in the application service that owns them.

Action context fields

The context passed to itemsProcessor, renderer, custom item run, and registered action run includes:

Field	Meaning
chart	The chart API instance.
object	The hovered chart object when one is available.
point	Local chart pixel point for the menu invocation.
time	Data-space timestamp projected from point, when available.
barIndex	Data index projected from point, when available.
price	Price/value projected from point, when available.

Configuration

Need	Surface
Disable the built-in right-click menu	features.contextMenu: false
Remove host-registered actions from SDK-rendered projection	features.actions: false (built-in shortcuts stay under features.shortcuts)
Enable/disable at the customization layer	ContextMenuCustomization.enabled
Hide the built-in scale-context section	scaleContextMenuVisible: false
Project specific host actions	ContextMenuCustomization.actionIds
Filter or reorder items	ContextMenuCustomization.itemsProcessor
Replace rendering entirely	ContextMenuCustomization.renderer
