Add Trusted Custom Indicators

Expected custom-indicator result rendered as an indicator in a TradeScript chart subpane
The trusted indicator is registered before mount, added by stable id, and verified through its plotted output and instance state.

Version 1 custom indicators are TypeScript modules shipped by the host application. Your build compiles the module; TradeScript registers the imported definition at application startup.

1. Define one stable indicator​

Keep the definition in its own .ts file. The id, input ids, and plot keys are storage identities; visible labels can change later.

const deskEma = indicator('Desk EMA', () => {
  const length = input.int('Length', 20, {
    id: 'length',
    min: 1,
    max: 500,
  });

  plot.line(ta.ema(close, length), {
    key: 'ema',
    title: 'EMA',
    color: '#22c55e',
  });
}, {
  id: 'desk-ema',
  compactLabel: 'EMA',
  pane: 'price',
});

Checkpoint: code review can identify every input, output, default, and visual key from this module without runtime string inference.

2. Register before creating an instance​

const registeredName = registerCustomIndicator(deskEma);

const indicatorId = await chart.addIndicator({
  name: registeredName,
  paneId: 'candle_pane',
  inputs: { length: 34 },
});

Registration is application startup work. Do not compile arbitrary user-provided source inside the chart.

Checkpoint: a green EMA line overlays the candles on the price pane, and the legend gains a Desk EMA row reflecting the length: 34 input rather than the default of 20.

3. Update through the chart API​

chart.updateIndicator(indicatorId, {
  inputs: { length: 55 },
});

Checkpoint: the plotted line recomputes with the longer period; the legend still shows one Desk EMA row, and no second indicator instance appears.

Verification​

  • The indicator appears on the intended pane with an EMA legend row.
  • Changing length updates the line without creating a second indicator.
  • Reloaded settings still use desk-ema, length, and ema.
  • The host validates user-entered values before calling updateIndicator. Custom-indicator input primitives coerce their received overrides; strict catalog validation is available only through updateBuiltInIndicatorProperties for built-ins.
  • Removing the indicator releases its chart-owned state.
Complete typed example
import {
  close,
  indicator,
  input,
  plot,
  registerCustomIndicator,
} from '@tradescript/pro/sdk/indicators';
import * as ta from '@tradescript/pro/sdk/indicators/ta';
import type { ChartApi } from '@tradescript/pro/sdk/core';

declare const chart: ChartApi;

const deskEma = indicator('Desk EMA', () => {
  const length = input.int('Length', 20, {
    id: 'length',
    min: 1,
    max: 500,
  });

  plot.line(ta.ema(close, length), {
    key: 'ema',
    title: 'EMA',
    color: '#22c55e',
  });
}, {
  id: 'desk-ema',
  compactLabel: 'EMA',
  pane: 'price',
});

const name = registerCustomIndicator(deskEma);
const indicatorId = await chart.addIndicator({
  name,
  paneId: 'candle_pane',
  inputs: { length: 34 },
});

chart.updateIndicator(indicatorId, { inputs: { length: 55 } });
